High environmental adaptability
Support 10 / 100m ethernet port and wifi/3G/4G
A variety of encryption methods
Simple setting methods，easy to use
1. High environmental adaptability
2. Support 10 / 100m ethernet port and wifi/3G/4G
3. A variety of encryption methods
4. Simple setting methods，easy to use
Hardware specifications | |
Chip set | l MT7620A+STM32F427+USB2514（Industrial-grade 32-bit communication processor） |
Core | l 580MHz MIPS24KEc Processor |
SDRAM | l 128MB |
NOR Flash | l 16MB |
NAND Flash | l 256MB |
Production specification | |
WAN port | l 1×10M/100M Ethernet interface（RJ45 jack），self-adaption MDI/MDIX, built-in 1.5KV insulation blocking |
Print interface | l Support USB、Parallel port、Serial port and Ethernet interface |
USB | l 2×USB2.0 |
SIM card interface | l 1×SIM card interface |
Serial port | l 1×RS232 |
WIFI | l Support IEEE802.11b/g/n/ac standard l IEEE802.11b/g；Maximum rate up to 108Mbps IEEE802.11n；Maximum rate up to 150Mbps IEEE802.11ac；Maximum rate up to 433Mbps l Support WEP、TKIP、AES、WPA、WAP2、WPAI and other variety of encryption methods，WPS function for option |
3G/4G | l Support 3G/4G network according to different configurations |
Power | l Maximum power dissipation：10W l External power adapter n Input：100-240V~50-60Hz 0.6A n Output：DC12V/1.5A n Lightning protection grade：4KV |
Product appearance | |
Button | l 1×Reset button，restore factory setting |
Antenna | l 1×External WIFI antenna，1×External 3G/4G antenna |
Size | l 160mm x 144mm x 50mm （W x L x H）（non include antenna） |
Other | |
Service environment | l Working temperature：-35℃ ~75℃ l Storage temperature：-40℃ ~85℃ l Working humidity：10% ~90% RH noncondensing l Storage humidity：5% ~90% RH noncondensing |
